16*2, 8-bit parallel, Character LCD Module, DGM1602-8036-2

DGM1602-8036-2 is a 16x2 Character dot Matrix LCD Display Module. It is known for high quality display effect with wide viewing angle and high contrast.

Product Description

16*2, 8-bit parallel, Character LCD Module, DGM1602-8036-2

DGM1602-8036-2 is a 16x2 Character dot Matrix LCD Display Module. It is known for high quality display effect with wide viewing angle and high contrast.

The module size is 80.0*36.0*13.0 mm (W*H*T) with 64.5*14.5 mm (W*H) viewing area. It accepts 8-bit parallel interface and 5V voltage. We have two display color options for DGM1602-8036-2: blue and yellow/green.

It is a perfect choice for copiers, fax machines, laser printers, industrial test equipment, networking equipment such as routers and storage devices.

More details please click here

Specifications:

Part No

DGM1602-8036-2

Resolution

16*2

Module size (W*H*T)

80.0*36.0*13.0 mm

Viewing Area (W*H)

64.5*14.5 mm

Character size (W*H)

2.9*5.15 mm

Dot size (W*H)

0.54*0.6 mm

VDD

5V

Operating temp

-20°C to 70°C

Storage temp

-40°C to 80°C

Weight

36g



Detail Image:



Character LCD Module,16*2 dots  DGM1602-8036-2
