Shrimp Deheading Machine

Shrimp Deheading Machine/Production Line



Model: ZL-QT100



Zolim Fish Processing Equipment in hot countries

Indonesia, Thailand, Vietnam, India, Malaysia, Philippines, Myanmar, Middle East, South Africa, Ecuador, Peru, Chile, Nicaragua, Russia, Brazil, Argentina, Egypt, Mexico, Venezuela, Australia, Europe, and the United States and other Marine countries.



The following equipment is an important component machine of the shrimp deveining line, such as:



1. Pouring machine

Technical parameters:

Machine dimensions: L2100xW1560xH1300mm

Pouring method: Hydraulic pump driven

Power: 2.2KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 300KG

Brief introduction: Pouring machine mainly lifts shrimp raw material or others by hydraulic pump to the lifting machine!

Application: shrimp, fish raw material, and others!



2. Lifting machine

Technical parameters:

Machine dimensions: L3500xW1300xH1600mm

Lift method: by high-strength nylon belt

Power: 1.5KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 500KG

Brief introduction: The lifting machine mainly lifts shrimp raw material by conveyor to the de-heading machine!

Application: shrimp, fish raw material, and others!



3. De-heading machine

Technical parameters:

Machine dimensions: L3200xW630xH1600mm

De-heading method: by drum

Power: 0.8KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 1500KG

Brief introduction: De-heading machine mainly puts shrimp head-on to the drum, then by run up and beat to achieve head and body separate!

Application: shrimp head-on!



4. Lifting machine

Technical parameters:

Machine dimensions: L2000xW1100xH1300mm

Lift method: by high strength nylon belt

Power: 0.4KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 400KG

Brief introduction: The lifting machine mainly lifts shrimp raw material by conveyor to another machine!

Application: shrimp, fish raw material, and others!



5. Lifting machine

Technical parameters:

Machine dimensions: L3000xW1550xH1700mm

Lift method: by high-strength nylon belt

Power: 1.5KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 450KG

Brief introduction: The lifting machine mainly lifts shrimp raw material by conveyor to the vibrator machine!

Application: shrimp, fish raw material, and others!



6. Vibrator machine

Technical parameters:

Machine dimensions: L1500xW1150xH1000mm

Power: 0.8KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 200KG

Brief introduction: Vibrator machine mainly lets shrimp raw material be placed more evenly through vibration!

Application: shrimp, fish raw material, and others!



7. Sizing machine

Technical parameters:

Machine dimensions: L4840xW2540xH1695mm

Pouring method: by differences in optical properties

Power: 4.5KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 2200KG

Precision:>=95%

Air compressor: 30kw

Bleed pressure: 0.3-0.6Mpa, Air consumption: 2.5-4.4m3/min, Air collector: 1.5m3

Brief introduction: The sizing machine mainly separates the shrimp head from the body by differences in optical properties!

Application: shrimp, and others!
