Concrete Pillar Machine

Precast concrete column machine is also known as concrete column machine or concrete column machine. The machine uses the principle of pushing and squeezing to manufacture pre-stressed columns with rectangular or square concrete sections.

Working guidelines

The Concrete Column Post Machine works on the principle of push technology. The machine runs on a bed of precast concrete or cast steel. The machine operation is powered by a drive motor and a vibration motor. Using the reciprocating linear motion of the slider, the loose concrete material in the hopper is continuously pushed into the molding cavity and the materials push each other. Due to the continuous operation of the vibrating plate, the concrete is highly plasticized. At the same time, the slider pushes the raw material to produce the reaction force so that the machine to overcome the frictional resistance, along the pre-stressing steel bar sliding forward, in the back of the machine to form a concrete component strip. The finished precast concrete column or post can be cut to the desired length.

Advantages of concrete column machine

Precast concrete column machine is small in size and light in weight, which makes it easy to relocate and transport when the production location changes.

The machine is easy to operate and maintain. Workers need only a little training to operate the machine.

High productivity. If the production site is large enough, one machine can theoretically produce at least 4,000 meters of columns in one working day.
