Rotary Vane Compressor Working Principle

Air compressors convert energy from electricity, natural gas or other sources into potential energy in the form of compressed air. The pressurized air can be released in a controlled manner to provide the kinetic energy required for its given application.

In principle, the design of an air compressor is relatively simple. Air enters the chamber through an inlet valve and is then pressurized by a reduction in chamber volume. When the compressor requires energy, the compressed air is released through the exhaust valve.

How do rotary vane compressors work?

All rotary vane compressors are equipped with a cylindrical rotor that is off-center of the housing. This rotor contains several partitions or walls that extend outward into the housing.

As air is drawn into the housing chamber through the inlet valve, the rotor rotates in a circular motion. As the rotor rotates, its walls squeeze the air trapped between the rotor and the edges of the housing into a progressively smaller space, which is why the rotor is off-center of the housing. This quickly pressurizes the air.

The now pressurized air is routed to the discharge valve where it can be released and used by a manual operator or automated process. The rotor continues to rotate and the cycle is repeated to maintain a steady flow of pressurized air.

Advantages of Rotary Vane Compressors

Rotary vane air compressors offer a variety of benefits, such as:

Efficiency. Rotary vane compressors are very energy efficient, with rotors typically spinning at 1,800 rpm or less.

 Longevity. Rotary vane compressors are extremely durable, with some compressors rated at over 100,000 hours of optimal service life.

 Flexibility. Rotary vane compressors are extremely versatile, serving a wide range of industries and applications.
