Mining Parts T-WIZ60-115mm Thread Retract Rock Drill Button Bit

Mining Parts T-WIZ60-115mm Thread Retract Rock Drill Button Bit

Product Description

Retractable threaded button bits in deep hole drilling operations, with high flatness, good stability, can meet the needs of large aperture use, widely used in underground mining, open-pit mining, hydropower engineering, quarry field and other engineering construction.

Brand Name MIROC
Material High strength alloy steel bar and tungsten carbide
Processing Type Forging
Application Mining / Quarrying / quarrying / Construction
Advantage Lower unit drilling cost
Color Green, Gold, Black or based on customer requirements.
Formation Soft , Medium , Hard , Very hard
Button bit shape Spherical, Ballistic,Conical
Face shape Flat shape and Drop-center shape
Body Type
Normal type and retract type
Thread connection R25, R28, R32, R38, T38, T45, T51, ST58, GT60
Certification ISO



Specification of retrac button bits

Product Code and Brief Description Bit Diameter (mm) Bit Diameter (inch) Front Buttons (No. x mm) Gauge Buttons (No. x mm) Angle Front Flushing Holes Side Flushing Holes Weight (kg)
T-WiZ60 Retrac Button Bit, 95 3 3/4 8x15 5x13 40° 4 - 6.5
Spherical Buttons
T-WiZ60 Retrac Button Bit, 102 4 8x16 5x13 30° 4 - 8
Spherical Buttons
T-WiZ60 Retrac Button Bit, 115 4 1/2 8x16 5x15 35° 4 - 9.8
Spherical Buttons
T-WiZ60 Retrac Button Bit, 127 5 8x16 5x15 40° 4 - 12
Spherical Buttons
T-WiZ60 Retrac Button Bit, 140 5 1/2 10x16 9x15 40° 4 - 15
Spherical Buttons
T-WiZ60 Retrac Button Bit, 152 6 16x16 4x15 35° 4 - 18
Spherical Buttons



Product Description

Retractable threaded button bits in deep hole drilling operations, with high flatness, good stability, can meet the needs of large aperture use, widely used in underground mining, open-pit mining, hydropower engineering, quarry field and other engineering construction.



Competitive Advantage

1.This type of bit is well known for its wear resistance on medium-hard to hard rock formations

2.Featuring spherical tungsten carbide inserts that is known to have strong configuration against carbide fracture

3.Widely used drifting and tunneling

4.Bit face design is ideal for medium-hard to hard rock formations



Quick detail of retract button bit:

• Widely used drifting and tunneling

• Bit face design is ideal for soft to medium rock formations

• With retrac wings to help guide the bit in and out of the hole

• Effective in straight hole drilling

Our service

• Competitive factory price

• Delivery on time

• Excellent after service

Elevate your drilling operations with our advanced top hammer drilling tools, meticulously designed to redefine industry standards and deliver exceptional results across diverse applications.
