Marine AH36 Ship Building Steel Plate Weight AH36 Ship Structure Steel Plate
Product Description
Country/Region：China
City：Zhengzhou
Product Attributes
- - Place of Origin China
- - Supply Type In-Stock Items
- - Condition New
- - Related Keywords AH36 Ship Building Steel, Ship Structure Steel, Ship Steel Plate, Ship Plate
Description by Manufacturer
marine ah36 ship building steel plate weight ah36 ship structure steel plate
AH36 steel is a kind of steel for shipbuilding and platform. AH36 ship structure steel plate is the high tensile strength steel. BBN steel passed classification societies certification of ABS, LR, BV, DNV GL, RINA, NK, CCS, KR, RMRS.
AH36 ship structure steel plate data sheet:
AH36 ship structure steel plate Specification | According to client's need |
| Technique | Hot rolled, TMCP |
| Density | 7.85 g/cm ³ |
| Additional Condition | Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, UT, The Third Party Test (such as SGS Test) |
AH36 ship structure steel plate chemical composition:
| C max | Si max | Mn | P max | S max | Al Min. | Cb | V | Ti max. | Cu max. | Cr max. | Ni max. | Mo max. | N max. |
| 0.18 | 0.10-0.50 | 0.90-1.60 | 0.035 | 0.035 | 0.015 | 0.02-0.05 | 0.05-0.10 | 0.02 | 0.35 | 0.20 | 0.40 | 0.08 | - |
AH36 ship structure steel plate mechanical property:
| Grade | Mechanical Property | Charpy V Impact Test | |||||
| Thickness | Yield | Tensile | Elongation | Degree | Transverse | Longitudinal | |
| AH36 | mm | Min Mpa | Mpa | Min % | 0 | J | J |
| t≤50 | 355 | 490-620 | 19% | 24 | 34 | ||
| 50<t≤70 | 355 | 490-620 | 19% | 27 | 41 | ||
| 70<t≤100 | 355 | 490-620 | 19% | 34 | 50 |
AH36 ship structure steel plate application:
AH36 ship structure steel plate is used primarily in shipbuilding, ship repair and other marine applications. The high strength characteristics and so on properties of AH36 ship structure steel plate meet the structural requirements of ships, barges, and other types of marine equipment.
