Huawei R4850N6 Rectifier Module 48V 3000W

The R4850N6 is a digital rectifier with high efficiency and power density. It converts a wide range of AC input voltage to 53.5 V DC output voltage.

Product Description

Huawei R4850N6 Rectifier Module 48V 3000W

Description

The R4850N6 is a digital rectifier with high efficiency and power density. It converts a wide range of AC input voltage to 53.5 V DC output voltage. The output voltage can be adjusted by the host. It performs comprehensive protection functions. With the latest power monitoring technology, states of the rectifier are monitored in real time. Multiple rectifiers can be paralleled.

Huawei rectifier module Key Features

Input voltage range: 85–290 V AC

Operating temperature range: –25ºC to +75ºC

Total harmonic distortion (THD): ≤ 5%

Digital control mode

Hot swap

Supports intelligent electric meter

Supports CAN communication

Supports LED display

Supports voltage adjustment, current adjustment,and current sharing

Meet RoHS requirement

Passes the CE.

Disconnect above 320V AC

Efficiency Peak efficiency: 94%;> 93% (230 V AC, 30%–100% load)
Height x Width x Depth 40.8 mm x105 mm x269 mm
Weight ≤ 2 kg
Cooling Built-in fan (fan speed adjustable)
Environmental Specifications
Operating temperature -25ºCto +75ºC
Storage temperature -40ºCto +75ºC
Relative humidity 5%-95% (non-condensing)
Altitude range ≤ 5000 m (When the altitude ranges from 3000 m to 5000 m, the operating temperature decreases by 1ºC for each additional 200 m.)
Electrical Specifications
Input
Operating voltage 85–290 V AC
Frequency 45–66 HzRated: 50 Hz and 60 Hz
Rated input current < 16 A
Maximum input current < 19 A
Power factor > 0.99 (load100%)
THD ≤ 5% (load ≥ 50% )
Output
Output voltage 42–58 V DCRated voltage: 53.5 V DC
Linear output power 3000 W(176 V AC–85 V AC)3000 W–1250 W(176 V AC–85 V AC)
Regulated voltage precision ≤±0.6%Vo
Ripple and noise ≤ 200 mVp-p(Bandwidth ≤ 20 MHz)
