Rochchip Android linux AIOT Core Board RK3588S SOM

Model: x3588SCV1

Optional configuration: RAM(LPDDR4)+ROM(eMMC) 4+16G and 8+32G

Rockchip Android linux IOT Core Board RK3588S SOM Features

Differences between RK3588S & RK3588 are,

1. RK3588S is more cheaper.

2. 1*HDMI RX2.1(RK3588S), 2*HDMI 2.1 TX(RK3588)

3. RK3588S have no PCIE3.0, only 1*SATA3.3 & PCIE2.1, RK3588 have PCIE3.0 & 2 x SATA3.3 & PCIE2.1

● Advanced 8nm processing, Rockchip new generation AIOT chip, 8K universal SoC.

● 8-cores ARM Framework, CPU 4*A76@2.4GHz & 4*A55@1.8GHz.

● Quad-Core GPU Mali-G610

● NPU 6TOPS AI computing power, support INT4/INT8/INT16 hybrid operation, support TensorFlow/MXNet/PyTorch/Caffe etc network model.

● 8K Encoder/Decoder Exploring, 8K@60fps H.265/VP9 video decoding & 8K@30fps H.265/H.264 video encoding, support decoding & encoding simultaneously, Max 32  1080P@30fps decoding &16 1080P@30fps encoding, HD 8K pictures.

● 8K display, Max 8K@60Hz, Can create a more realistic visual impression.

● Support HDMI2.1,  EDP1.3, MIPI-DSI, DP1.4, BT.1120 multi channel video output & HDMI RX2.0, MIPI-CSI, DVP video input, 8K multi channel video output & 4K video input, Can achieve multi screen with different content. Integrated with 48MP ISP with HDR & 3DNR, support MIPI-CSI double camera input.

● Various display interfaces, support for multiple hard drives, gigabit ethernet, WiFi6, 5G/4G extension；

● Support android12.0, debain, ubuntu etc.

● Comprehensive development documents；SDK, technical datasheet, tools.

Unlock the full potential of your Android, Linux, and AIoT applications with the rockchip core board. Experience unrivaled performance, flexibility, and scalability as you bring your ideas to life. Stay ahead of the curve and drive innovation with this powerful board that empowers your projects to reach new heights.

In summary, the rockchip core board, featuring the RK3588S SOM, offers exceptional performance, versatility, and scalability for Android, Linux, and AIoT applications. With its powerful processing capabilities, extensive connectivity options, and modular design, this board is the perfect choice for developers seeking to create groundbreaking solutions.

Applications:

• Edge computing box

• AGV

• ITX PC

• NVR

• Interative Kiosk

• AR/VR

• Clound Service

• Internet Media Player

Product Parameters
